SHANLING M0 PRO Music Player

M0 Pro is a full balanced audio circuit! With two pieces of ESS ES9219C DAC/AMPs, M0 Pro will be able to provide improved sound quality and increased output power. Making the most portable player sound even better!

To utilize the balanced output, while keeping the overall size of M0 Pro same as its predecessor, we got creative and implemented a brand-new type of 3.5mm connector, combining both single-ended and balanced connections into one. Working perfectly with all your standard single-ended 3.5mm connectors, while allowing for a proper balanced connection through a special 5-pin 3.5mm to 4.4mm adapter (Adapter sold separately).

And we can’t forget the bi-directional Bluetooth, such an important feature of the original. M0 Pro now packs an upgraded Bluetooth 5.0 chip, assuring compatibility with the latest Bluetooth headphones and improving connectivity.

Dimensions: 43.8 x 45 x 13.8

Weight: 36.8g

Display: 1.54-Inch 240 x 240

DAC: Dual ESS ES9219C

Memory: MicroSD card slot, up to 2TB support

Battery: 650 mAh

Battery Life: Up to 14.5 hours

Bluetooth 5.0

BT Codec Support: LDAC, aptX, AAC, SBC Transmitter / LDAC, AAC, SBC Receiver

Hi-Res support: 32 bit / 384 kHz & DSD128

Single-Ended Output

Output Power: 1.7 V @ 32 Ohm (90 mW)

Frequency Response: 20 Hz – 40 kHz

THD+N: 0.0006%

SNR: 118 dB @ 32 Ohm

Channel Separation: 72 dB @ 32 Ohm

Output Impedance: 0.4 Ohm

Balanced Output

Output Power: 2.75 V @ 32 Ohm (236 mW)

Frequency Response: 20 Hz – 40 kHz

THD+N: 0.0004%

SNR: 119 dB @ 32 Ohm

Channel Separation: 109 dB @ 32 Ohm

Output Impedance: 0.8 Ohm
